RDC 60 DATA COLLECTOR

RDC 60 Data Collector

Operating System

Android 14 (GMS)

Dimensions (L*W*H)

193.5*93*15mm

Memory & Storage

8GB + 128GB (1TB optional)

Display

6” IPS

RDC60 BROCHURE
VIEW PARTNER SITE

The RDC 60 Data Collector is the ultimate solution engeered for efficient field data collection. Featuring a full-constellation, multi-frequency GNSS positioning moudule, it achieves centimeter-level accuracy-perfectly meeting the diverse precision demands of GIS applications in urban planning, infrastructure inspection, resource management, smart water management, and environmental monitoring.

RDC60 Highlights

Designed Specifically for Outdoor Work

  • Meet a wide range of the test standards for operating in extreme temperatures (-20℃~+60℃);
  • Suitable for handling drops, vibrations, humidity and altitude (1.5m drop);
  • Powerful battery runtime (3.8V 8000mAh; removable).
  • IP68 Protection, fully dust-proof and water-proof;

Seamless Device Connection & Long Life Cycle

The RDC60 delivers a seamless connectivity experience with simple setup, automatic connection and reliable peformance. It intelligently selects or switched connection methods, allowing users to focus on core functionality without worring about connectivity complexity or interruptions.

  • Choose from a broad spectrum of communication technologies, including GNSS, Wi-Fi, Cellular Bluetooth and NFC;
  • SOC lifecycle 7 years;

User-friendly Operation

A specialized high-precision GNSS positioning module with a new anti-jamming antenna offers centimeter-level accuracy.

RDC60 eliminates the need for a complex differential account system, allowing for one-click fixation, ensuring precision and efficiency.

The RDC60’s anti-jamming antenna ensures reliable operation even in complex environments. No SDK is required, providing centimeter-level positioning services anytime, anywhere, with no complicated installation needed.

Lightweight design for easy prolonged carrying and one-handed operation. Its rugged construction withstands extreme temperatures, mositure, and dusty environments, ensuring ultimate reliability for field data protection. Reinforced corner bumpers absorb impact energy during accidental drops onto concrete, safeguarding the screen and motherboard.

RDC60 Application Areas

  • Emergency Response
  • Power Inspection
  • Citizen Services
  • Forestry Management
